JOHNFORD DMC-1600H HORIZONTAL MACHINING CENTER
JOHNFORD DMC-1600H HORIZONTAL MACHINING CENTER
Available quantity:1
Description
High-performance Johnford DMC-1600H Horizontal Machining Center equipped with a 20,000 RPM HSK-63 spindle, ideal for high-speed precision machining and heavy-duty production. Built with a rigid structure and large work envelope, this machine is perfect for aerospace, automotive, and mold applications.
Loaded with Fanuc 18i-MB control, chip conveyor, and 24-tool ATC, this unit is ready for immediate operation.
Specifications
| Manufacturer | Johnford |
| Model | DMC-1600H |
| Year | 2004 |
| Condition | Used |
| Stock Number | MAC-VMC-JFD-4018 |
| Pallet Size | 1700 x 1100 mm (66.9" x 43.3") |
| Distance between Columns | 1300 mm (51.2)” |
| X Axis Travel | 1600 mm (63.0") |
| Y Axis Travel | 1300 mm (51.2") |
| Z Axis Travel | 800 mm (31.5") |
| Spindle Nose to Table | 150 - 950 mm (5.9" - 37.4") |
| Spindle Speed | 20000 RPM |
| Spindle Motor | 23.5 HP |
| Rapid Traverse (X/Y/Z) | 15 / 15 / 12 m/min (590.6 / 590.6 / 472.4 ipm) |
| Cutting Feed Rate | 1 - 10000 mm/min (0.0 - 393.7 ipm) |
| Tool Capacity | 24 Tools (Arm Type) |
| Table Load Capacity | 6000 kg (13227.7 lb) |
| Machine Weight | 20400 kg (44973.0 lb) |
Equipped With
Fanuc 18i-MB CNC Control
Automatic Tool Changer (24 ATC)
Coolant Tank
Chip Conveyor
